Remote IO 1810

Features

LED Indicators for Diagnostics
Compact, pressure tolerant design
High Resolution Analog inputs
Pressure Tolerant
Daisy Chain
Water Detect
Individual frequency control for all channels
Dither function
Modbus RTU/UDP/TCP Protocol
Inbuilt switch / dual ethernet ports
Software switchable between RS232 and RS485
Web server for easy configuration

Description

The Ixys Remote IO 1810 is a standalone board for controlling proportional/on-off valves and reading sensors in demanding subsea and industrial environments. In total 18ea PWM outputs divided on 9ea output connectors for controlling valve solenoids. 10ea analog inputs for 4-20mA sensors. Input 5&6, 7&8 and 9&10 can in pairs be switched to digital NPN inputs with both raw on/off values and pulse counters to be used with incremental encoders or flowmeters.

Equipped with dual Ethernet ports and an inbuilt switch, the Remote IO 1810 supports Modbus RTU/UDP/TCP protocols and can be software-configured between RS232 and RS485 for maximum communication flexibility. A built-in web server allows simple configuration and monitoring via a standard web browser.

All outputs are disabled when the board is powered on. The PCB has a water detect input, which can be used to indicate water intrusion, and supply voltage measurement.
